The SP-8-2 is a high performance combiner splitter designed for satellite IF signals. The case is machined from Aluminium alloy and has a Nickel plated finish. Either N type or SMA connectors can be specified. | ||||||
| Parameter | Specification |
| Frequency range (MHz) | 800 - 2200 |
| Insertion Loss Typ/Max (dB) | 0.8/1.8 |
| Isolation Typ/Min (dB) | 25/20 |
| VSWR Typ/Max | 1.2/1.5 |
| Phase unbalance Max (deg) | 15 |
| Amplitude unbalance Max (dB) | 0.7 |
|
Notes Input and Output Impedance: 50ohmsConnectors: N female or SMA Power <1w Case: Aluminium Alloy Operation Temp: -35 to +80C |
 |
