The SP-2-14 is a high performance combiner splitter designed for satellite signals.
The case is machined from Aluminium alloy and has a Nickel plated finish.
| Home | Splitters home | Datasheet (pdf) | Contact |
|
The SP-2-14 is a high performance combiner splitter designed for satellite signals. The case is machined from Aluminium alloy and has a Nickel plated finish. |
||||||
| Model | Freq range (GHz) | Insertion Loss | Isolation | VSWR | Unbalance (deg) | Unbalance (dB) | Impedance |
| SP-2-14 | 10 - 14.5GHz | 0.5dB | 20dB | 1.1/1.35 | 12 | 50 ohm |
Notes
Input and Output Impedance: 50ohms
