| The SP2-2-10M-SW is a high performance combiner splitter with a switched 10MHz and DC path designed particularly for VSAT use when there are redundant modems. In the event of failure of the DC from the primary modem the combiner will switch and pass DC and 10MHz from the second modem to the Outdoor unit. Either N type or SMA connectors can be specified. | |||
| Parameter | Specification |
| Frequency range (MHz) | 800 - 2200 |
| Insertion Loss Typ/Max (dB) | 0.25/0.6 |
| Loss at 10MHz | <1dB |
| Isolation Typ/Min (dB) | 25/19 |
| VSWR Typ/Max | 1.1/1.35 |
| Phase unbalance Max (deg) | 2 |
| Amplitude unbalance Max (dB) | 0.2 |
Notes
Input and Output Impedance: 50ohms| Home | VSAT Combiners home | Datasheet (pdf) | Contact |
