2GHz Co-axial Isolator SMIS02A

The SMIS02A is a novel L band wideband Co-axial isolator designed for satellite signals. To achieve the large Bandwidth (800 to 2200MHz) and high specification it is an active implementation. The case is machined from Aluminium alloy and has a plated finish.

 Model  Freq range (GHz)  Insertion Loss  Isolation  Return Loss  Impedance (ohms)  Package
SMIS02A 800 - 2200MHz < 1.0dB 40dB >20dB min 50R, (75 R option) see below

Notes

Input and Output Impedance: 50ohms
Connectors:N type or SMA (F - M or F - F)
Also Available in 75 ohm with BNC or F type connectors
Case: Aluminium Alloy
Operation Temp: -35 to +70C
